Gigabyte Z790 AORUS ELITE AX-W, DDR5, SATA3, USB3.2Gen2x2, DP, 2.5GbE, WIFI 6E, LGA1700 ATX
PODNOŽJE: INTEL LGA1700ZA PROCESORJE:Intel 12/13thGeneration Core i7/i5/i3/Pentium/CeleronFORMAT: ATX Form Factor 30.5 x 24.4 cmVEZNI ČIP: IntelZ790 ExpressPOMNILNIK:4xDDR5 (7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000MHz)do skupno 128GB kapacitete, dual channel inExtreme Memory Profile (XMP)podpora,Support for nonECC /ECC Unbuffered DIMM(operate in nonECC mode),Sup
Znamka:Gigabyte
- Na zalogi
Gigabyte Z790 AORUS ELITE AX-W, DDR5, SATA3, USB3.2Gen2x2, DP, 2.5GbE, WIFI 6E, LGA1700 ATX
Trenutno najboljša ponudba:
312,98 €v Thrive shop
Podobni izdelki iz Osnovne (matične) plošče
Opis in lastnosti
PODNOŽJE: INTEL LGA1700ZA PROCESORJE:Intel 12/13thGeneration Core i7/i5/i3/Pentium/CeleronFORMAT: ATX Form Factor 30.5 x
24.4 cmVEZNI ČIP: IntelZ790 ExpressPOMNILNIK:4xDDR5 (7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.)
/6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 /
4000MHz)do skupno 128GB kapacitete, dual channel inExtreme Memory Profile (XMP)podpora,Support for nonECC /ECC
Unbuffered DIMM(operate in nonECC mode),Support for ECC Unbuffered DIMM 1Rx8/2Rx8 memory modules (operate in nonECC
mode), Support for nonECC Unbuffered DIMM 1Rx8/2Rx8/1Rx16 memory modulesGRAFIKA: preko CPURAID: DA
(0,1,5,10)RAZŠIRITVENE REŽE:1x PCIe 5.0/4.0/3.0 x16 (x16 mode)2 x PCIe 3.0 x16 (x4 mode)MREŽNA KARTICA:
Realtek2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) +WiFi 6E AX211WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz+
BLUETOOTH 5.3ZVOČNA KARTICA:Realtek High Definition AudioAudio CODECNOTRANJI PRIKLJUČKI:1 x 24pin ATX main power
connector2 x 8pin ATX 12V power connectors1 x CPU fan header1 x water cooling CPU fan header3 x system fan headers1
x system fan/water cooling pump header2 x addressable LED strip headers2 x RGB LED strip headers4 x M.2 Socket 3
connectors6 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB TypeC header, with USB
3.2 Gen 2 support1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers2 x Thunderbolt addin card connectors1 x Trusted
Platform Module header (For the GCTPM2.0 SPI/GCTPM2.0 SPI 2.0 module only)1 x reset button1 x QFlash Plus button1 x
Clear CMOS button1 x reset jumper1 x Clear CMOS jumperZUNANJI PRIKLJUČKI:1 x USB TypeC port, with USB 3.2 Gen 2x2
support2 x USB 3.2 Gen 2 TypeA ports (red)3 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports2 x SMA antenna connectors
(2T2R)1 x HDMI 2.0 port1 x DisplayPort1 x RJ45 port1 x optical S/PDIF Out connector2 x audio jacksDODATNO:iTE I/O
Controller ChipH/W MonitoringVoltage detectionTemperature detectionFan speed detectionWater cooling flow rate
detectionFan fail warningFan speed controlBIOS1 x 256 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM
2.0, SM BIOS 2.7, ACPI 5.0Unique FeaturesSupport for GIGABYTE Control Center (GCC)Support for QFlashSupport for
QFlash PlusSupport for Smart BackupBundled SoftwareNorton Internet Security (OEM version)LAN bandwidth management
softwareSpletna stran proizvajalca:https://www.gigabyte.com/Motherboard/Z790AORUSELITEAXWrev1x#kf
Lastnosti
Znamka | Gigabyte |
Oblika plošče | ATX |
Socket | Intel 1700 |
Vrsta pomnilnika | DDR5 |
GIGABYTE Z790 AORUS ELITE AX-W, DDR5, SATA3, USB3.2Gen2x2, DP, 2.5GbE, WIFI 6E, LGA1700 ATX
