PODNOŽJE: AMD AM4
ZA PROCESORJE: AMD RYZEN
FORMAT: mATX format 24.4 cm x 24 cm
VEZNI ČIP: AMD B450
POMNILNIK:
4 x DDR4 DIMM ECC/nonECC (do 4400(O.C) MHz) do skupno 128GB kapacitete dual channel podpora
GRAFIKA: DA preko APU
RAID: DA (0110)
RAZŠIRITVENE REŽE:
1 x PCI Express x16 PCIEX16
1 x PCI Express x16 PCIEX8
1 x PCI Express x16 PCIEX4
2 x PCI Express 2.0 x1
MREŽNA KARTICA: Realtek RTL8111H LAN chip (10/100/1000Mbit) z ASUS LANGuard
ZVOČNA KARTICA: Realtek ALC887 codec High Definition Audio (2/4/5.1/7.1channel)
NOTRANJI PRIKLJUČKI:
1 x CPU Fan connector(s) (1 x 4 pin)
2 x Chassis Fan connector(s) (2 x 4 pin)
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s) (19pin)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 3 with M key type 2242/2260/2280/22110 storage devices support (SATA & PCIE 3.0 x 4 mode)
1 x SPI TPM header
1 x COM port(s) connector(s)
6 x SATA 6Gb/s connector(s)
1 x S/PDIF out header(s)
1 x 24pin EATX Power connector(s)
1 x 8pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s)
1 x Clear CMOS jumper(s)
1 x COM port header
1 x Speaker connector
1 x RGB Header
ZUNANJI PRIKLJUČKI:
1 x PS/2 keyboard/mouse combo port(s)
1 x DVID
1 x DSub
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.2 Gen 2 (teal blue) (2 x TypeA)
4 x USB 3.2 Gen 1 (blue) TypeA
3 x Audio jack(s)
1 x BIOS FlashBack™ Button(s)
DODATNO:

ASUS Exclusive Software
Armoury Crate
AURA Creator
AURA Sync
AI Suite 3
Performance and Power Saving Utility
TurboV EVO
EPU
DIGI+ VRM
Fan Xpert 2+
PC Cleaner
EZ update
System Information
ASUS CPUZ
AI Charger
ASUS EZ Installer
DAEMON Tools
Norton Antivirus software (Free Trial for 60 days)
WinRAR
UEFI BIOS
ASUS EZ DIY
ASUS CrashFree BIOS 3
ASUS EZ Flash 3
ASUS UEFI BIOS EZ Mode
ASUS Special Features
ASUS 5X PROTECTION III
ASUS DIGI+ VRM
ASUS LANGuard
ASUS Overvoltage Protection
ASUS SafeSlot Core
ASUS StainlessSteel Back I/O
ASUS QDesign
ASUS QDIMM
ASUS QSlot
ASUS Thermal Solution
Aluminum heatsink design
ASUS EZ DIY
BIOS FlashBack™ button
BIOS FlashBack™ LED
AURA Sync
AURA RGB header
ASUS Lighting Control

Spletna stran proizvajalca: https://www.asus.com/MotherboardsComponents/Motherboards/PRIME/PRIMEB450MAII/
