PODNOŽJE: AMD AM5ZA PROCESORJE: AMD RYZEN 7000/8000 SeriesFORMAT: ATX format 30.5 cm x 24.4 cmVEZNI ČIP: AMD B650POMNILNIK:4 x DDR5 DIMM nonECC8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400MHz (odvisno od procesorja)do skupno 192GB kapacitete, dual channel inEXtended Profiles for Overclocking,Extreme Memory Profile (XMP)podporaGRAFIKA: DA preko APURAID: DA (0,1,10)RAZŠIRITVENE REŽE:CPU:1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16)Chipset:1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x1 (PCIEX1)Support for AMD CrossFire technology (PCIEX16 and PCIEX4)MREŽNA KARTICA: Intel 2.5GbELAN chip (10/100/1000Mbit/2.5Gbit) ;AMD WiFi 6E RZ616,a, b, g, n, ac, ax, supporting 2.4/5/6 GHz, BLUETOOTH 5.2ZVOČNA KARTICA: Realtek ALC1220VB CODECAudio High Definition Audio (2/4/5.1/7.1channel)NOTRANJI PRIKLJUČKI:1 x 24pin ATX main power connector1 x 8pin ATX 12V power connector1 x 4pin ATX 12V power connector1 x CPU fan header1 x water cooling CPU fan header4 x system fan headers2 x system fan/water cooling pump headers2 x addressable LED strip headers2 x RGB LED strip headers1 x CPU cooler LED strip/RGB LED strip header3 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x front panel header1 x front panel audio header1 x USB TypeC header, with USB 3.2 Gen 2x2 support1 x USB 3.2 Gen 1 header2 x USB 2.0/1.1 headers1 x noise detection header1 x THB_U4 addin card connector1 x Trusted Platform Module header (For the GCTPM2.0 SPI/GCTPM2.0 SPI 2.0 module only)1 x serial port header1 x QFlash Plus button1 x reset button1 x reset jumper2 x temperature sensor headers1 x Clear CMOS jumperZUNANJI PRIKLJUČKI:2 x SMA antenna connectors (2T2R)2 x USB 2.0/1.1 ports1 x DisplayPort In port1 x HDMI port3 x USB 3.2 Gen 2 TypeA ports (red)1 x USB TypeC port (DisplayPort), with USB 3.2 Gen 2 support4 x USB 3.2 Gen 1 ports1 x RJ45 port2 x audio jacks1 x optical S/PDIF Out connectorDODATNO:iTE I/O Controller ChipH/W MonitoringVoltage detectionTemperature detectionFan speed detectionWater cooling flow rate detectionFan fail warningFan speed controlNoise detectionBIOS1 x 256 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique FeaturesSupport for GIGABYTE Control Center (GCC)Support for QFlashSupport for QFlash PlusBundled SoftwareNorton Internet Security (OEM version)LAN bandwidth management softwareSpletna stran proizvajalca:https://www.gigabyte.com/Motherboard/B650AEROGrev10#kf
