Gigabyte B650M AORUS ELITE AX ICE, DDR5, SATA3, USB3.2Gen2x2, DP, 2.5GbE, WiFi 6E, AM5 mATX
PODNOŽJE: AMD AM5ZA PROCESORJE: AMD RYZEN 7000 SeriesFORMAT: mATX format 24.4 cm x 24.4 cmVEZNI ČIP: AMD B650POMNILNIK:4 x DDR5 DIMM nonECC6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400MHz (odvisno od procesorja)do skupno 128GB kapacitete, dual channel inEXtended Profiles for Overclocking,Extreme Memory Profile (XMP)podporaGRAFIKA: DA preko APURAID: DA (0,1,10)RAZŠIRITVENE REŽE:1 x PCI Express 3.0/4.0 x161 x PCI Express 3.0 x4MREŽNA KARTICA:Realtek2.5GbELAN
Znamka:Gigabyte
- Na zalogi
Gigabyte B650M AORUS ELITE AX ICE, DDR5, SATA3, USB3.2Gen2x2, DP, 2.5GbE, WiFi 6E, AM5 mATX
Trenutno najboljša ponudba:
252,60 €v Thrive shop
Podobni izdelki iz Osnovne (matične) plošče
Opis in lastnosti
PODNOŽJE: AMD AM5ZA PROCESORJE: AMD RYZEN 7000 SeriesFORMAT: mATX format 24.4 cm x 24.4 cmVEZNI ČIP: AMD B650POMNILNIK:4
x DDR5 DIMM nonECC6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400MHz (odvisno
od procesorja)do skupno 128GB kapacitete, dual channel inEXtended Profiles for Overclocking,Extreme Memory Profile
(XMP)podporaGRAFIKA: DA preko APURAID: DA (0,1,10)RAZŠIRITVENE REŽE:1 x PCI Express 3.0/4.0 x161 x PCI Express 3.0
x4MREŽNA KARTICA:Realtek2.5GbELAN chip (10/100/1000Mbit/2.5Gbit) ;AMD WiFi 6E RZ616,a, b, g, n, ac, ax, supporting
2.4/5/6 GHz, BLUETOOTH 5.2ZVOČNA KARTICA: Realtek Audio codec High Definition Audio (2/4/5.1/7.1channel)NOTRANJI
PRIKLJUČKI:1 x 24pin ATX main power connector1 x 8pin ATX 12V power connector1 x CPU fan header1 x water cooling CPU
fan header3 x system fan headers1 x system fan/water cooling pump header2 x addressable LED strip headers2 x RGB LED
strip headers1 x CPU cooler LED strip/RGB LED strip header2 x M.2 Socket 3 connectors4 x SATA 6Gb/s connectors1 x
front panel header1 x front panel audio header1 x USB TypeC header, with USB 3.2 Gen 2x2 support1 x USB 3.2 Gen 1
header2 x USB 2.0/1.1 headers1 x serial port header1 x THB_U4 addin card connector1 x Trusted Platform Module header
(For the GCTPM2.0 SPI/GCTPM2.0 SPI 2.0 module only)1 x reset button1 x reset jumper1 x Clear CMOS jumperZUNANJI
PRIKLJUČKI:1 x QFlash Plus button2 x SMA antenna connectors (2T2R)1 x DisplayPort1 x HDMI port1 x USB TypeC port,
with USB 3.2 Gen 2 support2 x USB 3.2 Gen 2 TypeA ports (red)5 x USB 3.2 Gen 1 ports4 x USB 2.0/1.1 ports1 x RJ45
port1 x optical S/PDIF Out connector2 x audio jacksDODATNO:iTE I/O Controller ChipH/W MonitoringVoltage
detectionTemperature detectionFan speed detectionWater cooling flow rate detectionFan fail warningFan speed
controlBIOS1 x 256 Mbit flashUse of licensed AMI UEFI BIOSPnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Unique
FeaturesSupport for GIGABYTE Control Center (GCC)Support for QFlashSupport for QFlash PlusBundled SoftwareNorton
Internet Security (OEM version)LAN bandwidth management softwareSpletna stran
proizvajalca:https://www.gigabyte.com/Motherboard/B650MAORUSELITEAXICE#kf
Lastnosti
Znamka | Gigabyte |
GIGABYTE B650M AORUS ELITE AX ICE, DDR5, SATA3, USB3.2Gen2x2, DP, 2.5GbE, WiFi 6E, AM5 mATX
